Specifications
Type | Dimension | per pile | per meter run | |||||||||
b | h | t | S | Mass | S. Area | Ix | Zx | Mass | S. Area | Ix | Zx | |
mm | mm | mm | mm | kg/m | cm2 | cm4 | cm3 | kg/m2 | cm2/m | cm4/m | cm3/m | |
LARSSEN 755 | 750 | 450 | 11.7 | 10.0 | 95.6 | 121.8 | 9,431 | 580 | 127.5 | 162.4 | 45,000 | 2,000 |
LARSSEN 703 | 700 | 400 | 9.5 | 8.0 | 67.5 | 86.0 | 5,630 | 414 | 96.4 | 122.9 | 24,200 | 1,210 |
LARSSEN 703 K | 700 | 400 | 10.0 | 9.0 | 72.1 | 91.8 | 5,830 | 426 | 103.0 | 131.1 | 25,950 | 1,300 |
LARSSEN 703 10/10 | 700 | 400 | 10.0 | 10.0 | 75.6 | 96.3 | 5,960 | 437 | 108.0 | 137.6 | 26,800 | 1,340 |
LARSSEN 704 | 700 | 440 | 10.2 | 9.5 | 80.5 | 102.5 | 7,910 | 529 | 115.0 | 146.4 | 35,200 | 1,600 |
LARSSEN 600 | 600 | 150 | 9.5 | 9.5 | 56.4 | 71.8 | 850 | 130 | 94.0 | 119.7 | 3,825 | 510 |
LARSSEN 600 K | 600 | 150 | 10.0 | 10.0 | 59.4 | 75.6 | 880 | 133 | 99.0 | 126.1 | 4,050 | 540 |
LARSSEN 601 | 600 | 310 | 7.5 | 6.4 | 46.8 | 59.0 | 2,650 | 251 | 78.0 | 98.3 | 11,520 | 745 |
LARSSEN 602 | 600 | 310 | 8.2 | 8.0 | 53.4 | 68.0 | 2,790 | 265 | 89.0 | 113.3 | 12,870 | 830 |
LARSSEN 603 | 600 | 310 | 9.7 | 8.2 | 64.8 | 83.0 | 3,830 | 330 | 108.0 | 138.3 | 18,600 | 1,200 |
LARSSEN 603 K | 600 | 310 | 10.0 | 9.0 | 68.1 | 87.0 | 3,890 | 340 | 113.5 | 145.0 | 19,220 | 1,240 |
LARSSEN 603 10/10 | 600 | 310 | 10.0 | 10.0 | 69.6 | 89.0 | 4,067 | 350 | 116.0 | 148.3 | 19,530 | 1,260 |
LARSSEN 604 n | 600 | 380 | 10.0 | 9.0 | 73.8 | 94.0 | 5,700 | 415 | 123.0 | 156.7 | 30,400 | 1,600 |
LARSSEN 605 | 600 | 420 | 12.5 | 9.0 | 83.5 | 106.4 | 7,910 | 520 | 139.2 | 177.3 | 42,420 | 2,020 |
LARSSEN 605 K | 600 | 420 | 12.2 | 10.0 | 86.7 | 110.4 | 8,080 | 537 | 144.5 | 184.1 | 42,630 | 2,030 |
LARSSEN 606 n | 600 | 435 | 14.4 | 9.2 | 94.2 | 120.0 | 9,870 | 565 | 157.0 | 200.0 | 54375 | 2,500 |
LARSSEN 628 | 600 | 456 | 16.3 | 9.8 | 99.3 | 126.5 | 10,000 | 584 | 165.5 | 210.8 | 63,380 | 2,780 |
LARSSEN 607 n | 600 | 452 | 19.0 | 10.6 | 114 | 145.0 | 11,280 | 649 | 190.0 | 241.7 | 72,320 | 3,200 |
LARSSEN 22 10/10 | 500 | 340 | 10.0 | 10.0 | 65 | 82.8 | 4,180 | 369 | 130.0 | 165.6 | 22,100 | 1,300 |
LARSSEN 23 | 500 | 420 | 11.5 | 10.0 | 77.5 | 98.7 | 7,480 | 527 | 155.0 | 197.4 | 42,000 | 2,000 |
LARSSEN 24 | 500 | 420 | 15.6 | 10.0 | 87.5 | 111.0 | 8,270 | 547 | 175.0 | 222.0 | 52,500 | 2,500 |
LARSSEN 24/12 | 500 | 420 | 15.6 | 12.0 | 92.7 | 118.1 | 8,397 | 560 | 185.4 | 236.2 | 53,610 | 2,550 |
LARSSEN 25 | 500 | 420 | 20.0 | 11.5 | 103 | 131.0 | 8,850 | 562 | 206.0 | 262.0 | 63,840 | 3,040 |
LARSSEN 43 | 500 | 420 | 12.0 | 12.0 | 83 | 106.0 | 6,230 | 483 | 166.0 | 212.0 | 34,900 | 1,660 |
LARSSEN 430 | 708 | 750 | 12.0 | 12.0 | 83 | - | - | - | 234.5 | 299.4 | 241,800 | 6,450 |
