Specifications
Model: JIS 22kg
Standard: JIS E 1103-91
Weight: 22.3 kg/m
Material: 55Q (Medium carbon steel)
Length: 6–12 meters, 12.5–25 meters, or customized lengths upon request
Model | DIMENSION | Weight | Material | Length | |||
A(mm) | B(mm) | C(mm) | t(mm) | (KG/M) | (m/PC) | ||
JIS 22KG | 50.8 | 93.66 | 93.66 | 10.72 | 22.3 | 55Q | 9-10 |
Drawing
Contact Us
Hanzi is China's largest rail manufacturer. If you are interested in our rails or have any questions, please contact us for further information and a quote.
The JIS 22kg light rail is designed to meet the rigorous requirements of JIS E 1103-91 and JIS E 1101-93 (Japanese Industrial Standards), offering exceptional durability for medium-to-heavy load applications. Manufactured from Q235B carbon steel, this rail combines high tensile strength with excellent weldability and corrosion resistance, making it suitable for long-term use in demanding industrial and mining environments.
Hanzi offers a wide range of rails—including light rails (such as the JIS 22kg rail), heavy rails, and crane rails—available in various standards and specifications.
