Specifications
Model: JIS 30kg
Standard: JIS E 1103-93
Weight: 30.1 kg/m
Material: 55Q (Medium carbon steel)
Length: 6–12 meters, 12.5–25 meters, or customized lengths upon request
Model | DIMENSION | Weight | Material | Length | |||
A(mm) | B(mm) | C(mm) | t(mm) | (KG/M) | (m/PC) | ||
JIS 30A | 60.33 | 107.95 | 107.95 | 12.3 | 30.1 | 55Q | 9-10 |
Drawing
Contact Us
Hanzi is China's largest rail manufacturer. If you are interested in our rails or have any questions, please contact us for further information and a quote.
The JIS 30A rail (also known as the JIS 30kg rail) is designed to meet the rigorous requirements of JIS E 1103-93 and JIS E 1101-93 (Japanese Industrial Standards), offering exceptional durability for medium-to-heavy-duty applications. Manufactured from either Q235B carbon steel (equivalent to JIS SS400) or 55Q high-strength steel, this rail combines high tensile strength with excellent weldability and corrosion resistance, making it suitable for long-term use in demanding industrial and mining environments.
Hanzi offers a wide range of rails—including light rails (such as the JIS 30A), heavy rails, and crane rails—available in various standards and specifications.
Hanzi is one of China's largest manufacturers of steel sheet piles. It produces high-quality steel sheet piles in various types and sizes, widely used in port construction, offshore breakwaters, deep foundation pit support, integrated pipeline corridors, subways, bridges, tunnels, and other applications.
