Specifications
Model: CR100 Rail
Standard: JIS E1103-93 / JIS E1101-93
Weight: 100.2 kg/m
Material: U71Mn
Length: 6–12 meters, 12.5–25 meters, or customized lengths upon request
Model | DIMENSION | Weight | Material | Length | |||
A(mm) | B(mm) | C(mm) | t(mm) | (KG/M) | (m/PC) | ||
CR 100 | 120 | 150 | 155 | 39 | 100.2 | U71Mn | 10-12 |
Drawings
Contact Us
Hanzi is China's largest rail manufacturer. If you are interested in our rails or have any questions, please contact us for further information and a quote.
The CR100 is a heavy-duty rail specifically designed for large-scale industrial crane systems. With its robust profile and superior strength, it ensures stable and safe operation in environments such as ports, shipyards, and heavy manufacturing plants. Manufactured from U71Mn alloy steel in compliance with Japanese and Korean standards (JIS E1101-93), the rail offers a combination of high strength and wear resistance, enabling it to withstand the rigorous demands of frequent crane operations.
Hanzi offers a wide range of rails—including light rails, heavy rails, and crane rails (such as the CR100)—available in various standards and specifications.
