Specifications
Model: ASCE 20
Standard: ASCE
Weight: 20 lb/yd (9.91 kg/m)
Material Grade: 700
Length: 6–12 m, 12.5–25 m, or custom lengths upon request
Profiles | Weight | Head width | Height | Base width | Web | |||||
kg/m | lb/yd | mm | in | mm | in | mm | in | mm | in | |
ASCE20 | 9.92 | 20.00 | 34.13 | 111/32 | 66.67 | 25/8 | 66.67 | 25/8 | 6.35 | 1/4 |
Drawing
Contact Us
Hanzi is a leading rail manufacturer in China. If you are interested in our rails or have any questions, please contact us for further information and a price quote.
The ASCE 20 rail features a T-shaped cross-section (20 lb/yd, approx. 9.95 kg/m) and complies with ASCE standards. It is supplied in lengths of 6 or 8 meters, comes pre-drilled with fishplate holes, and is available with a choice of finishes: mill finish (natural), primed, or painted. Designed for medium-duty track applications, it balances strength, flexibility, and cost-effectiveness, making it suitable for light-duty cranes, underground mining transport, and automated monorail systems.
Hanzi offers a wide range of rail products—including light rails, heavy rails, and crane rails (such as the ASCE 20)—available in various standards and specifications.
